Type 1:

Wall mount
Type 2:

Inverter
Capacity(BTU):

18000
TR (Ton Range):

1.5 TON
Rated Cooling Capacity (W):

5300 (700~5600)
EER (W/W):

2.93
Power Supply (Volt/Phase/Hz):

1/230/50HZ
Rated Power Input (W):

1750 (260~2200)
Rated Current (A):

8.0 (1.1~9.6)
Max. Current (A):

9.0
Indoor air flow (Hi/Mi/Lo) m3/h:

800
Compressor Type:

Rotary
Refrigerant Type:

R32
Refrigerant Standard (Kg):

0.85
Refrigerant Pipe Dia (mm) Liquid Side/Gas Side:

6/12
Evaporator/Condenser:

100% 7mm Grooved Copper
Heat Exchangers:

Golden Fin
Indoor noise level (Hi/Mi/Lo) [dB(A)]:

46/42/38
Outdoor noise level [dB(A)]:

55

Air Flow Direction

Up & Down:

Auto
Left & Right:

Auto

Net Weight

Indoor (Kg):

11.5
Outdoor (Kg):

32.5

Net Dimension (WxDxH)

Indoor (W*D*H) mm:

875*217*307
Outdoor (W*D*H) mm:

800*280*553

Package Dimension (WxDxH)

Indoor (W*D*H)mm:

945*296*390
Outdoor (W*D*H)mm:

902*375*614

User Functions

Wifi:

Yes
UVC Technology:

Yes
Energy Savings:

Yes (Up to 65%)
Dry Mode:

Yes
Self Clean:

Yes
ECO Mode:

Yes
Turbo Function:

Yes
Auto Restart Function:

Yes
Sleep Mode:

Yes
Low Noise:

Yes
Timer:

Yes
Quick & Easy Installation:

Yes
Child Lock:

Yes

• 12(Twelve) years Compressor Grantee.

  04 (Four) years spare parts Grantee.

  02(Two) years Free service.

  installation charge & Angle- Free

  with10fit copper pipe,

  Extra copper pipe pare fit 400/-

  Without vat  & tax.

  Without delivery .
•
